SPECIFICATIONS
120mm Fan Options: 9
140mm Fan Options: 2
Application: Desktop
Brand Name: Jonsbo
Case Size: 305mm (W) *353mm (D) *318mm (H)
Case Weight: 7.5
Chassis Type: Desktops
Choice: yes
Dust Filters: TOP
Form Factor: MicroATX,ITX
Front Ports: USB3.2 Gen2 Type-Cx1 / USB3.0x1 AUDIOx1+MICx1 2in1
High-concerned chemical: none
Hot-Swap Drive Bays: 0
Internal 2.5" Drive Bays: 9
Internal 3.5" Drive Bays: 9
Material: STEEL
Max CPU Cooler Height: 160
Max GPU Length: 320
Max PSU Length: 220
Model Number: N6
Origin: Mainland China
Power Model: ATX
Power Supply Mounted: TOP
RGB Support: NO RGB
Radiator Size: 240mm
Series: N6
Type: Horizontal
With Fan: Yes
With Power Supply: no
With Side Panel Window: no
semi_Choice: yes
Product Parameters
Product model: N6
Color: Black
Product size: 305mm (W) * 353mm (D) * 318mm (H) (including 6mm high footrest)
Material: 0.7mm+1.0 steel plate
Hard disk space: 2.5 "SSD * 9 or 3.5" HDD * 9
Motherboard support: ITX/M-ATX
PCI expansion slots: 4
Front interface: USB 3.2 Gen2 Type-C * 1/USB 3.0 * 1 (AUDIO * 1+MIC * 1 2-in-1)
Power supply: ATX ≤ 220mm/SFX ≤ 100mm (supports dual power mode)
CPU heatsink: ≤ 65-160mm
Graphics card support length: ≤ 275mm-320mm
Cooling system: Front panel 120mm * 2 or 140mm * 2/Rear panel 120mm * 1/Left side 120mm * 2/Right side 120mm * 2/Hard drive compartment 120mm * 2 (standard)
Speed controller: 3-port/3-speed fan speed controller (standard)
Water cooling support: 240mm
Weight: 7.5kg (net weight)
