SPECIFICATIONS
120mm Fan Options: 13
140mm Fan Options: 2
Application: Desktop
Brand Name: Jonsbo
Case Size: 460.2mm * 310.3mm* 476.5mm
Case Weight: 12.2
Chassis Type: Desktops
Choice: yes
Dust Filters: Rear
Expansion Slots: 0
Form Factor: ATX
Front Ports: USB3.2 Gen1 Type-A*2 / USB3.2 Gen 2 Type-C*1 / AUDIO*1 & MIC*1
High-concerned chemical: none
Hot-Swap Drive Bays: 0
Internal 2.5" Drive Bays: 1
Internal 3.5" Drive Bays: 2
Material: others,ABS/ Aluminum Frame
Max CPU Cooler Height: 176
Max GPU Length: 427
Max PSU Length: 180
Model Number: X400
Origin: Mainland China
Power Model: ATX
Power Supply Mounted: Bottom
RGB Support: A-RGB
Radiator Size: 360mm
Series: X400
Type: Horizontal
With Fan: no
With Power Supply: no
With Side Panel Window: Yes
semi_Choice: yes
Product Parameters
The difference between X400 and X400 PRO:
X400: The panel/frame is made of ABS engineering plastic+2H hard coating
X400 PRO: The panel/frame is made of aluminum alloy material
X400 PRO GRAY
Product model: X400 PRO GRAY
Chassis materials: SPCC&SECC, ABS plastic, tempered glass, aluminum alloy
Chassis size (including footrest): 460.7mm * 310.9mm * 476.8mm (depth/width/height)
Compatible motherboards: MINI-ITX/MICRO-ATX/ATX, compatible with back plug motherboards
Drive bit: 2.5 "SSD: 1 unit
3.5-inch HDD: up to 2
Front interface: USB 3.2 Gen 1 Type-A * 2/USB 3.2 Gen 2 Type-C * 1/AUDIO * 1&MIC * 1
Fan: Top: 3 * 120mm/2 * 140mm (optional); Side: 3 * 120mm (optional); Back: 2 * 120mm (optional); Rear: 2 * 120mm (optional); Bottom: 3 * 120 (optional)
Water cooling support: top 240mm/280mm/360mm specification cold row; Side: 360mm specification cold row
ATX PS2 power supply compatibility: ≤ 180mm
CPU heatsink supports a height limit of 176mm
GPU compatible size: limited to 427mm in length
Weight: Net weight 11.3kg/Gross weight 13.1kg
X400
Product model: X400
Chassis materials: SPCC&SECC, ABS plastic, tempered glass
Chassis size (including footrest): 460.2mm * 310.3mm * 476.5mm (depth/width/height)
Compatible motherboards: MINI-ITX/MICRO-ATX/ATX, compatible with back plug motherboards
Drive bit: 2.5 "SSD: 1 unit
3.5-inch HDD: up to 2
Front interface: USB 3.2 Gen 1 Type-A * 2/USB 3.2 Gen 2 Type-C * 1/AUDIO * 1&MIC * 1
Fan: Top: 3 * 120mm/2 * 140mm (optional); Side: 3 * 120mm (optional); Back: 2 * 120mm (optional); Rear: 2 * 120mm (optional); Bottom: 3 * 120 (optional)
Water cooling support: top 240mm/280mm/360mm specification cold row; Side: 360mm specification cold row
ATX PS2 power supply compatibility: ≤ 180mm
CPU heatsink supports a height limit of 176mm
GPU compatible size: limited to 427mm in length
Weight: Net weight 10.2kg/Gross weight 12.2kg
