SPECIFICATIONS
Brand Name: S.M.S.L
DSD Sampling Frequencies: 2.8224 MHz (DSD64),5.6448 MHz (DSD128),11.2896 MHz (DSD256),22.5792 MHz (DSD512)
Electrified: No
High-concerned chemical: none
Inputs: USB Type-C
Material: Plastic
Origin: Mainland China
Outputs: Balanced Out
PCM Sampling Frequencies: 44.1 kHz,48 kHz,88.2 kHz,96 kHz,176.4 kHz,192 kHz,352.8 kHz,384 kHz,705.6 kHz,768 kHz
PCM Word Length: 16-bit,24-bit,32-bit
Type: Portable
SMSL DAC MINI Apple-Optimized Flagship DAC for Studio-Grade Audio with Ultra-low Distortion Studio-rade Measurements
Key Selling Points
Designed specifically for Mac mini desktop setups
Patented front-panel Mac smart power-on system
ESS ES9039Q2M flagship DAC + XMOS XU-316
Ultra-low distortion, studio-grade measurements
Powerful balanced & single-ended headphone outputs
USB 3.0 expansion hub integration
CNC all-aluminum minimalist chassis
Designed for Mac mini. Built for Pure Sound
The SMSL DAC MINI is a compact, desktop-grade DAC and headphone amplifier engineered specifically for seamless integration with Mac mini setups. Combining minimalist industrial design, patented Mac smart power-on control, and flagship ESS DAC architecture, it delivers studio-grade audio performance while redefining desktop convenience.
Perfect Partner for Your Mac mini
A specially designed front-mounted power button solves the long-standing inconvenience of powering on a Mac mini. With a single tap, both devices power up instantly—no bending, no guesswork.
Suspended Support Architecture
A custom trapezoidal aluminum stand precisely aligns the DAC MINI with the Mac mini, forming a stable, unified desktop structure that looks intentional and elegant.
CNC All-Aluminum Chassis
Finished in custom silver-gray, the CNC-machined aluminum body delivers durability, excellent heat dissipation, and a refined Apple-style aesthetic.
ESS ES9039Q2M + XMOS XU-316
At the core is ESS’s flagship ES9039Q2M DAC paired with the high-performance XMOS XU-316 USB processor, accurately restoring original studio recordings with ultra-low distortion.
Laboratory-Grade Measurements
With THD+N as low as 0.0001% and a dynamic range up to 122dB, DAC MINI delivers exceptionally clean, transparent audio output.
Deeply Optimized for macOS
Driver-free operation on macOS ensures stable performance and effortless plug-and-play integration within Apple’s ecosystem.
Powerful Headphone Amplification
Both 3.5mm single-ended and 4.4mm balanced outputs easily drive in-ear monitors and full-size over-ear headphones with authority and control.
2-in-1 Optical / Coaxial Digital Output
The combined optical/coaxial output enables flexible integration with speakers, amplifiers, and home entertainment systems.
Patented Mac Smart Power-On System
Through precise physical contact between front-panel controls and the Mac mini power button, DAC MINI enables cross-device startup within 0.1 seconds—turning every press into a refined ritual of efficiency.
USB-C to USB-A Hub (USB 3.0)
The built-in USB 3.0 port supports high-speed data transfer for flash drives, external storage, and card readers, reducing desktop clutter.
Snap-Fit Alignment Design
An elastic snap-fit structure prevents slipping, keeps cables neatly aligned, and maintains a clean, organized workspace.
Specifications
DAC Chip: ESS ES9039Q2M
USB Processor: XMOS XU-316
Headphone Outputs: 3.5mm SE / 4.4mm Balanced
Line Output Level: 2Vrms
Headphone Output Power:
32Ω: up to 265mW ×2
150Ω: up to 120mW ×2
300Ω: up to 60mW ×2
600Ω: up to 30mW ×2
THD+N:
Line Out: 0.000125% (-118dB)
Headphone Out: 0.000178% (-115dB)
Dynamic Range: up to 122dB
SNR: up to 121dB
PCM: 44.1kHz – 768kHz / 32bit
DSD: DSD64 – DSD512
DoP: DoP256
USB Compatibility: Windows 7/8/8.1/10/11 (driver required), macOS 10.6+, Linux(driverless), Android
Power Consumption: <4W
Standby Power: <0.3W
Dimensions: 127 × 28.2 × 133.6 mm (W × H × D)
Weight: 0.244 kg / 0.538 lbs
Meta Description
SMSL DAC MINI is a compact desktop DAC and headphone amplifier designed for Mac mini. Featuring ESS ES9039Q2M DAC, patented smart power-on control, balanced headphone output, and studio-grade performance in a minimalist aluminum chassis.
